20W
Solar lighting solution for the modern home
Looking for reliable and efficient solar panels? Look no further than d.light's 20W solar panels. Designed with cutting-edge technology, these panels deliver exceptional power output and efficiency to meet your energy needs.
d.light's 20W solar panels are perfect for a range of applications, from charging your devices on outdoor adventures to providing sustainable lighting solutions in off-grid areas. With their compact and portable design, they are easy to install and transport, making them ideal for camping trips, RVs, and emergency situations.
Experience the convenience of clean energy with d.light. Our 20W solar panels are built to withstand various weather conditions, ensuring durability and long-term performance. Say goodbye to expensive electricity bills and embrace a sustainable future.
Invest in d.light's 20W solar panels and join the movement towards renewable energy. With their high efficiency and reliability, you can power your devices, reduce your carbon footprint, and contribute to a greener world. Take control of your energy needs and unlock the benefits of solar power with d.light's 20W solar panels.
- Quality – Superior EVA encapsulation for enhanced durability
- Efficiency – Higher cell efficiency for charging batteries and devices faster
- Coating – Anti-reflective coating and back surface (BSF) absorb more light for better performance
- Compliance – Strict adherence to all IEC standards for higher performance delivery
- Frame – Lightweight and durable weather-resistant aluminium frame
- Cells – A Grade superior power cells
Save more on electricity bills with d.light solar panels. Charge small appliances such as mobile phones and DC LED lights and even provide a power source for your inverters and batteries with the d.light solar panels range which is available in options ranging from 10W to 335W. d.light solar panels are manufactured from high quality polycrystalline cells and high-strength aluminium frame for better torsion resistance against extreme weather conditions. Its Anti-reflective coating and back surface (BSF) absorb more light for better performance even in cloudy and low light conditions. The Advanced Ethyl Vinyl Acetate (EVA) encapsulation brings enhanced durability and protection.
| Module Dimensions (L X W X H) in mm. | 435 x 350 x 17 |
| Weight (KG) | 1.75 |
| Junction Box/ Terminal Box | NA |
| Cables and connectors | NA |
| Superstrate | High Transmission Low Iron Tempered Glass |
| Cells | 36 Polycrystalline Cells |
| Solar Cell shape | Square |
| Solar cell geometry in mm | 77x39 |
| Backsheet | Composite film |
| Frame | Anodized Aluminium Frame |
| Packaging Method | 10 Mono cartons in 1 master carton |
| Electrical characteristics | |
| Power (Pm) in Watts (nominal) 20W | |
| Open Circuit Voltage (Voc) in Volts 22 | |
| Short Circuit Current (Isc) in Amps 1.22 | |
| Voltage at Maximum Power (Vmp) in volts 18 | |
| Current at maximum Power (Imp) in Amps 1 | |
| Maximum system Voltage (VDC) 600 | |
| Module Efficiency ? (%) >10 | |
| Voltage | 12V |
